性能項目ltem |
指標Specification |
遵從標準Standard |
材料類型Type of material |
柔性橡塑發泡材料
Flexible rubber foam material |
GB/T17794-2008 |
外觀Appearance |
黑色Black |
|
泡孔結構Foam structure |
完全閉泡
Completely closed bubble |
|
表現密度Kg/m³Density |
≤95 |
GB/T6343 |
氧指數Oxygen index |
≥32% |
GB/T2406 |
煙密度等級SDR |
≤75 |
GB/T8627 |
導熱系數
Condu ctivity factor
|
0℃時≤0.034
-20℃時≤0.031
40℃時≤0.036 |
GB/T10294 |
透濕性能Water
Vapor permeability |
透濕系數Coefficient |
≤2.8×10﹣¹¹ |
GB/T17146-1997 |
濕阻因子Factor |
≥7.0×10³ |
真空吸水率%
Water absorption ratio in vacuum |
≤10 |
GB/T17794-2008 |
燃燒性能
Flammability |
難燃B1級 |
GB8624-1997 |
當用于建筑領域時,不低于C級
When the product is used in the
construction sector,the level is not
less than C-class |
GB8624-2006 |
燃燒產煙毒性
Toxicity of smoke form burning |
ZA3安全等級
Security level |
GA132-1996 |
尺寸穩定性%105℃±3℃,7d
Dimension stability |
≤10 |
GB8811 |
撕裂強度Crack resistance N/cm |
≥2.5 |
GB/T10808 |
壓縮回彈率% 壓縮率50%,72h ratio
Compression resilien ceratio, Compression |
≥70 |
GB/T6669-2001 |
耐臭氧性Anti-ozone
臭氧分壓202mPa,200h Anti-ozone |
不龜裂Not cracking |
GB/T7762 |
抗老化性150h Aging resistance |
輕微起皺,無裂紋,無針孔,不變形slightly crumpling,no cracks
No pin holes, not deforming |
GB/T16259 |
適用溫度范圍℃Temperature range |
-40-110 |
GB/T17794 |
